Do you know which Beta Air filter you need for your Beta engine?
Use our guide to help you.
Equivalent to Beta part number 211-08132
Description
Filter is capped with a blue or black rubberised type cap.
Filter housing: For use with plastic filter housing with twist off lid.(Notmetal type with spring clips)
Filter Element Dimensions
- Diameter approx across rubberised cap: 102mm
- Height approx:102mm
For use on Beta Engines
Beta10, Beta14, Beta16, Beta 20 & Beta 25 FROM MARCH 2011 (PLASTIC BODY filter housing)
Beta 35 & Beta 38 – FROM JAN 2012
Beta 30 & Mechanical gearbox – FROM MARCH 2011
_______________________________________________________________________________________________________
Description: No cap. You can see right though the centre. Pan type
Filter housing: 3 clamp steel body type
Filter Element Dimensions
- Diameter approx 150mm
- Height approx: 73mm
For use on Beta Engines
Beta 30 / Hydraulic gearbox – TO END 2010 (Housing is 3 clamp steel body type)
Beta 35 & Beta 38 –TO END 2010 (Housing is 3 clamp steel body type)
Beta43, Beta 50 and Beta 60 – (Housing is 3 clamp steel body type)
Also Fits D905 to V1505 Beta Generators.
_______________________________________________________________________________________________________
Equivalent to Beta part number 211-62950
Description: Tall Baked Bean can size filter. No cap, you can see through the centre.
Filter housing: 2 CLAMP TYPE – STEEL BODY FILTER HOUSING
Filter Element Dimensions
- Diameter approx: 96mm
- Overall height approx: 106mm
For use on Beta Engines
Beta10, Beta 13.5, Beta14, Beta16, Beta 20 & Beta 25 up to MARCH 2011 (2 CLAMP TYPE – STEEL BODY FILTER HOUSING)
Beta 30 / Mechanical gearbox –TO MARCH 2011 (2 CLAMP TYPE – STEEL BODY FILTER HOUSING)
For use on Beta Engines
Beta Ten, Beta 16, Beta 25, BZ 482, BD 722 (Beta Mini Series) Beta 28 BD1005 (later model)
__________________________________________________________________________________________________
Equivalent to Beta part number 211-61833
Description: No cap. You can see right though the centre.
Filter Element Dimensions
- Diameter approx 142mm
- Height approx: 90mm
For use on Beta Engines
Beta 30 / Hydraulic gearbox – FROM 2011
Beta 35 & Beta 38 –TO END 2011 (STEEL BODY – CENTRAL WING NUT FIXING)
Beta 43, Beta 50 and Beta 60 (STEEL BODY – CENTRAL WING NUT FIXING)
Filter Housing STEEL BODY – CENTRAL WING NUT FIXING see photo below
_____________________________________________________________________________________________________
Equivalent to Beta part number 211-09179
Description: Filter is capped with a blue or black rubberised type cap.
Filter Element Dimensions
- Diameter approx 138mm
- Height approx: 87mm
For use with Beta 60, 50, 43, heat Exchanger and Keel Cooled Engines,
Beta engines from 2014 with Plastic Body Filter Housing
